Hand Held (Portable) and Table Top Thermocouple /
mV / mA Calibrator








Hand Held (Portable)
Display 4 ½ Digit LCD
Range 200 mV / 20 mA
Source Out Put 0 to 199.99 mV
0 to 19.999 mA
Measure Input 0 to ±199.99 mV
O to ±19.999 mA
Accuracy 0.05 % ± 2 Count
mA Load 500 E Max
Out Put 10 Turn POT Coarse & Fine
Op. Temp. 0 to 50 °C ( RH <80%)
Supply 9 V Dc battery x 2
Includes Test Leads, Thermocouple Table &
Traceable calibration certificate

Table Top
3 ½ Digit LED 4 1/2Digit LCD
200 mV/μA 2 V / mA 20 v / mA
0 to 199.9
0 to 199.99		 0 to 1.999
0 to 1.9999		 0 to 19.99
0 to 19.999
0 to ±199.9
0 to ±199.99		 0 to ± 1.999
0 to ± 1.9999		 0 to ±19.99
0 to ±19.999
3 ½ Digit 0.1 %
± 2 count		 4 ½ Digit 0.05%
± 2 count
1 K E Max
10 Turn POT Coarse & Fine
0 to 50 °C ( RH <80%)
230 V AC ± 10% 50 Hz
110 V AC ( Optional)
Test Leads, Thermocouple Table &
Traceable calibration certificate
